Smart Dual Power Controller 80A Automatic Transfer Switch for Off Grid Solar Wind System ATS DC 12/24/48V AC 110/220V

New Tuya Smart Bluetooth Dual Power Controller 80A 16KW Automatic Transfer Switch Energy Saving for Off Grid Solar Wind System ATS DC 12V 24V 48V AC 110V 220V MOES APP for Smart Control with Bluetooth Hub

BY  MOES

Main Features:

• 【The new MOES APP is compatible with Tuya APP intelligent control, saving energy and saving electricity】

• 【Smart Monitor on Electrical Values with Surge Protection】

• 【Auto Distinguish with Adjustable Set-points and AC Test】

• 【Bigger Power:Updated rated power:8KW(110V) or 16KW(220V) and 80A,Large LCD screen is designed to display voltage and working status

• 【On cloudy or windless days when your battery gets low,it will automatically switch to grid power to protect your battery,especially for the condition that when battery voltage is lower than cut off point,it will automatically switch back to battery power when the battery voltage is higher than recovery point,working like an opposite direction UPS with the updated manual switch function for your convenience.】

⭐Note:
1.The controller needs to connect the battery, powered by the battery and get battery power data;includes full 2-year warranty and 60-day refund guarantee for complete satisfaction.

Energy Saving

• Turn your backup power supply into an energy-saving device

Application Area

Comparison between the 3rd and

4th Generation

Upgrade points

• Updated rated power:8KW(110V) or 16KW(220V) and 80A

• Automatically switch to public power when the inverter AC output is abnormal

• Surge Protection

• Added manual switch working mode, free adjustment

• Intelligent, can control and view the situation through the mobile APP

Bluetooth Smart Power

System with MOES APP Compatible

• Smartly monitor and switch values in the APP in a much easier way.

• MOES APP compatible ensures its smart controls by APP for flexible transfer and usage between the public power and battery

• Featured with the three functional values as grid power,automatic mode and inverter power in the APP for power supply,clarifying the concept of energy-saving in a real-sense.

• ( All functions on the ATS itself work without any interference to the APP.)

Large LCD Display among Automatic Mode,

Grid Power and Inverter Power

• Designed with large LCD display for showing battery real-time voltage,working status of public power,inverter and battery.

Product Function

Dual power transformer AUTO transfer bettwen Public power& battery.

• On cloudy or windless days when your battery gets low,it will automatically switch to grid power to protect your battery,especially for the condition that when battery voltage is lower than cut off point.

• It will automatically switch back to battery power when the battery voltage is higher than recovery point

• Note: It can be switched manually

• DC 12/24/48V,AC 100-120V 60HZ / 220-240V 50HZ auto distinguish

• User can define the Cut-Off and Recovery Voltage. Recovery voltage must be higher than Cut-off voltage.

• Suitablefor various battery types as Sealed,Gel,Lead-acid,Lithium battery and so on,the battery low voltage transfer and battery recovery set-points are freely adjustable up to the battery type.

• AC test is functional well as the device will automatically switch to public power when the inverter AC output is abnormal.

Wireless Remote Control under Bluetooth Hub

  Note:

• Bluetooth hub is required for remote control when out of Bluetooth control  range

• Bluetooth hub is required for smart scene automation,but with fast network pairing featured under phone Bluetooth and 2.4G WiFi.

Surge Protection

• Durable surge resistance to protect electrical appliances

• Timely access to the current voltage of grid,battery and inverter,specially the current,power and electricity consumption of the load,performing as the advanced power system with surge protection featured for over-current protection.

Fast speed

• The transfer speed is extremely fast for seamless switching with no influence on devices usage

• The computer will keep working with no power off during the switchingperiod.

• Fast Transfer time:Inverter transfer to public power ≤10ms,public power transfer to inverter ≤16ms

Updated Design with New Features/Product Parameter

SPECIFICATION

•



  Specification:

  • Model:BAT-80A

  • Rated Power:8kw (Utility Power 100-120V)

  •                      16kw (Utility Power 220-240V)

  • Input Voltage:Auto Selection: AC 100-120V or AC 220-240V

  • Output Voltage:Auto Selection: AC 100-120V or AC 220-240V

  • Transfer time:Inverter transfer time to utility power

  •                       Utility power transfer time to inverter

  • LCD Display:Battery voltage; Power source: Utility power or battery-inverter.

  • System Voltage:Auto Select: 12V or 24V or 48V

  • Battery low voltage transfer set-points:Default: 10.5V/21V/42V, adjustable

  • Battery recovery set-points:Default: 12.5V/25V/50V, adjustable

  • Application:Off grid solar system; Wind generator; Hydro generator

  • Product Size:19*17*7.25cm(7.4″*6.7″*2.8″in)

  • N.W/PC:
    1.32KG(2.9lbs)



  Q&A:



  1.Q:
   Can I have the correct wiring diagram because the manual is showing that the Neutral is going to the line side on the public power?

  A: White wire to white wire black to black green to green.Watch this video please:  //www.youtube.com/watch?v=ni0A_ZdH7aU

  2.Q:
   Is this compatible for grid power 220v 60hz? because the grid power in our area is 220-240v 60hz.

  A: It says 220-240 50hz but it will work with 60hz as it doesn’t monitor the frequency. It’s just a big switch which switches between supplies when the batteries supplying your inverter reach a preset level.

  3.Q:
   Can I wireless monitor the public voltage on smart phone when I am not at home?

  A: Yes,it’s the new update Tuya smart version compatible with MOES APP for smart control.

  4.Q:
  Is it the hub required for APP configuration?

  A: You can pair the new ATS into the APP with WiFi and Bluetooth,but with Bluetooth hub required for wireless remote control and smart scene automation.
